R28 Hex Speedrod Drift Rod 3050mm For Small Drilling Hole

Name: R28 Hex Speedrod Drift Rod 3050mm For Small Drilling Hole
Brand: MIROC
Price: 1 USD

Buy cheap R28 Hex Speedrod Drift Rod 3050mm For Small Drilling Hole product

Brand Name : MIROC

Model Number : R32 R38

Certification : API, ISO9001

Place of Origin : China (Mainland)

MOQ : 5pcs

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30000pcs per Month

Delivery Time : 5-15 Work Days

Packaging Details : Steel Bundle

Product Name : SpeedRod

Material : High Quality Steel

Processing Type : Forging

Use : Mining,tunneling, mining,quarrying

Length : 2400mm to 3050mm

Color : Customize

Applicable : Mine drilling

Machine Type : Drilling Equipment

Thread : R28

Contact Now

R28 Hex Speedrod Drift Rod Extension Rod 3050mm For Small Drilling Hole

Description:

The benefits of short threads on hexagonal drill rods include superior resistance to bending stresses, improved bit guidance and outstanding energy transfer. The sturdy thread is well supported inside the bit skirt, resulting in high precision collaring – even in complex rock formations and against uneven surfaces.

INDUCTION SURFACE HARDENING + THREADS

– Hard, wear-resistant surface

– Improved fatigue strength

– Induction hardening of threads

– Rapidly heated and cooled

Basic Information

Product Name	Hex Speedrod / Drift Rod / Extension Rod
Material	Carbon Steel
Color	As customer's requirements
Body Type	Round shape and hexagonal type
Thread type	R28,
Diameter	28mm-32mm
Type	Drifter/ speed/extension/HX extension / MF rod
Length	2400mm-6400mm

Both surface hardened (male part) and fully carburized (female part)

Drifter Rod R32-Hex 28-R28
	Length (mm)	Dia.(mm)	Weight (KG)	Part Number
1	2400	28	12.2	4148300770
2	2750	28	12.8	4148300771
3	3700	28	15.3	4148300772
4	4000	28	20.4	4148300773
5	4310	28	22.0	4148300774
6	4920	28	25.3	4148300775
Drifter Rod R38-Hex 32-R28
8	2900	39	18.8	4148300777
9	3090	39	20.0	4148300778
10	3700	39	24.0	4148300779
11		39	27.9	4148300780
Drifter Rod R32-Hex 32-R28
	Length (mm)	Dia.(mm)	Weight (KG)	Part Number
1	3090	32	20.0	4148300781
2	3700	32	23.5	4148300782
Extension Rod R28-Hex 28-R28
1	3050	28	15.0	4148300784
Speed Rod R28-Hex 28-R28
1	3050	28	15	4148300786
